Kwh Meter Thera TEM091N-L7220

Deskripsi THERA TEM091N-L Series, kWh Meter Prabayar 1-Phase Sistim Kartu (IC)

THERA TEM091N-L Series, kWh Meter Prabayar 1-Phase Sistim Kartu ( Chip Card)

Model: TEM091N-L Series
Tipe : TEM091N-D7220 Rating 5(60)A
Quick Spec.: LED Display, Direct Connection kWh Prabayar 1-Phase/2-Wire 230VAC/50Hz, 5(60)A, Class 1.0

FUNCTIONS:
TEM091N-L Series adalah kWh meter Prabayar 1-Phase elektronik sistim kartu (Chip Card) yang digunakan umtuk
mengukur besarnya pemakaian listrik/energi dalam kWh yang dapat disi ulang dengan berupa pulsa listrik ysng
dapat di beli di pengelola gedung/Admin.

FEATURES:
– Accuracy class 1.0
– Wide rage current measurement
– Front Board/Wall Mounting
– SO output
– Easy installation
– Smart IC Card (Chip)
– Light Weight & Good reliability

SPECIFICATIONS:
– Measuring: kWh (konsumsi energy listrik Prabyar)
– Accuracy Class: Class 1.0
– Display: 5+1 Digits LED Display

– Reference Voltage (Un): 230V AC / 50+10% Hz
– Network Mode: Direct Connection ,1-Phase/2-Wire
– Operating Voltage: 161 – 279 V AC
– AC Voltage withstand: 4 KV for 1 minute
– Impulse Voltage: 6kV-1.2/50µS waveform

– Rate Current (Ib) / (Imax): 5 / (60)A
– Operating Current Range: 0.4%Ib ~ Imax
– Internal Power Consumption: <2W/10VA

– Index Protection of Dust/Water: IP51 Class II
– Authority International Standard IEC 62053-21 dan DIN EN50022
– Sudah di test di Balai Metrologi / Tera Indonesia

COMMUNICATIONS PORT:
– Pulse Output rate / meter constant (Open Collector): 1600 imp/kWh

TEMPERATURE & HUMIDITY:
– Operating Humidity Range <75%
– Storage Humidity Range <95%
– Operating Temperature Range -15 C ~ + 50 C
– Storage Temperature Range -30 C ~ + 70 C

DIMENSIONS (W x H x D):
W: 110 mm x H: 201 mm x D: 68 mm.

ORDERING CODE:
TiPE : TEM091N-L7220 Untuk Rating : 5(60)A, Ready Stock ( Sales priority ).
