Kwh Meter Digital Thera 3 Phase TEM021N-D58G3

THERA TEM021-D Series, LCD 7-Module DIN-Rail 3-Phase kWh/Energy Meter

Model : TEM021-D Series
Tipe : TEM021-D85G3 Rating Direct Conn. 3 x 5(100)A
Tipe : TEM021-D05F3 Rating Indirect Conn. 3 x CT../5A

FUNCTIONS:
TEM021-D Series adalah LCD 7-Module DIN-Rail kWh/Energy Meter Elektronik 3 Phase Untuk
Mengukur Besarnya Pemakaian Listrik/Energi KWh Pada Jaringan 3-Phase.

FEATURES:
– Wide rage current measurement
– Programmable CT ratio
– Rs485 & InfraRED port
– Test/SO pulse output port
– DIN-Rail Mounting & Size 7-DIN modules
– Easy Installation

SPECIFICATIONS:
– Measuring : kwh (mengukur Konsumsi Listrik/Energi jaringan 3-Phase)
– Connecting Mode: Direct & InDirect Conn. Via CT
– Accuracy Class: Class 1.0
– Display: 6(5+1) digits LCD Display

– Reference Voltage (Un): 3 X 230/400V AC (3~)
– Operating Voltage: 3-Phase/4-Wire, 161/279-300/520V AC (3~)
– AC Voltage withstand: 2 KV for 1 minute
– Impulse Voltage: 6kV-1.2/50µS waveform

– Rate Current (Ib) / (Imax) : 1.5(5)A Via CT and 5(100)A Direct
– Operating Current Range: 0.2%Ib ~ Imax Via CT or 0.5%Ib ~ Imax for Direct
– Operating Frequency: 50 Hz +/- 10%
– Internal Power Consumption: <2W/10VA /Phase

– Index Protection of Dust/Water: IP51 Class II
– Authority International Standard IEC 62053-21 dan DIN EN50022
– Sudah termasuk Sertifikat test Tera Indonesia

COMMUNICATIONS PORT:
– Pulse Output (Open Collector): 3600 imp/kWh for CT & 10 kWh/imp for Direct
able to connect to THERA TMEX16DI Pulse Concentrator Module.
– RS485 & InfraRED Port with Protocol DL-645/2007 able to connect
to THERA PCREAD METER Software

TEMPERATURE & HUMIDITY:
– Operating Humidity Range <75%
– Storage Humidity Range <95%
– Operating Temperature Range -15 C ~ + 50 C
– Storage Temperature Range -30 C ~ + 70 C

DIMENSIONS (W x H x D):
(W x H x D) W: 125 mm x H: 88 mm x D: 73 mm

Keunggulan Produk :

– Bentuk lebih kecil dan tidak terlalu berat.

– Menggunakan sistem layar digital.

– Penghitungan Akurat.

– Lulus Uji Sertifikasi Tera Badan Meterologi.

– Kwh Meter model digital yang cocok digunakan untuk tempat berskala terbatas dan layar berbentuk lcd display mudah dilihat, macam” tipenya kami lampirkan : TEMS011, TEMS015, TEMS021, TEMS031, TEMS041, TEMS035D, TEMS045D, TEMS065D,dll

– Bergaransi Selama 1 Tahun.
