Kwh Meter 3 Phase Analog CT Thera TEM021-C05C0

Model : TEM021-C Series
Tipe : TEM021-C85G0 Rating Direct Conn. 3 x 5(100)A
Tipe : TEM021-C05C0 Rating Indirect Conn. 3 x CT../5A
Quick Spec.: Reg. Display, 3P/4W, 3×230/400VAC/50Hz, Class 1

FUNCTIONS:
TEM021-C Series adalah 7-Module DIN-Rail kWh/Energy meter elektronik tiga fase
untuk mengukur besarnya pemakaian listrik/energi kWh pd jaringan 3-Phase.

FEATURES:
– Wide rage current measurement
– Test/SO pulse output port
– DIN-Rail Mounting & Size 7-DIN modules
– Easy Installation

SPECIFICATIONS:
– Measuring : kwh (mengukur Konsumsi Listrik/Energi jaringan 3-Phase)
– Connecting Mode: Direct & InDirect Conn. Via CT
– Accuracy Class: Class 1.0
– 6 (5+1) digits Reg. Counter Display

– Reference Voltage (Un): 3 X 230/400V AC (3~)
– Operating Voltage: 3-Phase/4-Wire, 161/279-300/520V AC (3~)
– AC Voltage withstand: 2 KV for 1 minute
– Impulse Voltage: 6kV-1.2/50µS waveform

– Rate Current (Ib): 5A Via CT and 5A & 10A Direct
– Maximum Rates Current (Imax): 6A Via CT or 100A Direct
– Operating Current Range: 0.2%Ib ~ Imax Via CT or 0.5%Ib ~ Imax for Direct
– Operating Frequency: 50 Hz +/- 10%
– Internal Power Consumption: <2W/10VA /Phase

– Index Protection of Dust/Water: IP51 Class II
– Authority International Standard IEC 62053-21 dan DIN EN50022
– Sudah termasuk Sertifikat test Tera Indonesia

COMMUNICATIONS PORT:
– Pulse Output (Open Collector): 1600 imp/kWh for CT & 160 imp/kWh for Direct
Suite able to connect to THERA TMEX16DI Pulse Concentrator Module.

TEMPERATURE & HUMIDITY:
– Operating Humidity Range <75%
– Storage Humidity Range <95%
– Operating Temperature Range -15 C ~ + 50 C
– Storage Temperature Range -30 C ~ + 70 C

DIMENSIONS (W x H x D):
(W x H x D) W: 125 mm x H: 88 mm x D: 73 mm

Garansi Produk 1 Tahun.
